Description

I. Product overview
NI SCXI-1302, as a terminal module, is mainly used to connect and wire measurement signals. It connects the signal leads of sensors, signal sources and other devices to modular measurement systems for data acquisition, testing and control. This module is usually used in conjunction with other modules in the SCXI series, such as data acquisition modules, signal conditioning modules, etc., to achieve a more comprehensive measurement and control system.

2. Main functions and characteristics
Signal connection:
The NI SCXI-1302 provides multiple signal connection ports for connecting external signal leads to the module. These ports support a variety of signal types, such as voltage, current, etc., to meet different measurement needs.
Multiplexer features:
The module has a Multiplexer function that allows multiple input signals to be connected to a single acquisition channel. This function can realize the switch between different signals, improve the flexibility and efficiency of data acquisition.
Connection convenience:
The terminal modules are designed to facilitate user wiring to simplify the signal connection and configuration process. The user can connect the signal source to the measurement system through a simple wiring operation.
Adapters and connectors:
Equipped with adapters and connectors to ensure stability and reliability of signal connections. These adapters and connectors can be adapted to different types of signal lines and interfaces to ensure the accuracy and reliability of signal transmission.
Shielding design:
The SCXI-1302 has a shielding design to reduce the impact of external electromagnetic interference on the signal. This design helps to improve the accuracy and stability of signal measurement.
Installation options:
The module has rack mounting and DIN rail mounting options, so users can choose the right mounting method according to their actual needs. This flexibility allows the SCXI-1302 to be adapted to different measurement environments and scenarios.
Stress relief fixture:
Equipped with stress relief clamps to ensure the signal lines are firmly in place. This design helps reduce measurement errors and failures caused by loose or falling signal lines.
3. Application fields
NI SCXI-1302 is widely used in laboratory testing, data acquisition, sensor measurement, automation control and other fields. It can be used with other modular measurement system modules to build powerful measurement and control systems. For example, in industrial automation, the SCXI-1302 can be used to monitor various parameters on the production line (such as temperature, pressure, flow, etc.) and transmit the data to the control system for processing and analysis.
