Description

The NI SCXI-1180 is a data acquisition module manufactured by National Instruments (NI) and belongs to the Signal Conditioning eXtensions for Instrumentation (SCXI). That is, instrument signal conditioning extension) series. The following is a detailed analysis of NI SCXI-1180:

I. Product overview
The NI SCXI-1180 module is designed for data acquisition and signal conditioning, providing high-precision, multi-channel signal input and conditioning capabilities. It is usually used in conjunction with NI’s SCXI chassis to achieve signal acquisition, conditioning, conversion and transmission. The module is widely used in the fields of industrial automation, test and measurement, scientific research and experiment, and meets the needs of data acquisition in various complex environments.

Two, the main characteristics
High precision data acquisition:
NI SCXI-1180 module supports high-precision data acquisition, and can accurately capture various analog signals to ensure the authenticity and reliability of data.
Multi-channel design:
The module usually has multiple input channels, which can collect multiple signals at the same time, improve the efficiency and flexibility of data acquisition. The number of channels may vary depending on the product model and configuration.
Signal conditioning function:
The built-in signal conditioning circuit supports the amplification, attenuation, filtering and other processing of the input signal to adapt to different signal types and measurement needs.
Programmability:
It supports configuration and control through programming, and users can write programs according to actual needs to realize complex control logic and data acquisition strategy.
Modular design:
As part of the SCXI family, the NI SCXI-1180 module can be used in combination with other SCXI modules for more powerful data acquisition and signal conditioning capabilities.

3. Application fields
The NI SCXI-1180 module is widely used in the following fields:

Industrial Automation:
In the production line to achieve signal acquisition and monitoring, to ensure the stability and reliability of the production process.
Test and measurement:
It is used in various test and measurement equipment to achieve high-precision signal acquisition and analysis.
Scientific research experiment:
As a data acquisition device in scientific research experiments, it supports researchers to collect, process and analyze data.
