Description

I. Product overview
Brand: NI (National Instruments Corporation)
Type: PXI Express chassis
Number of slots: 18 slots, including 8 hybrid slots, 8 PXI Express slots, and 1 PXI Express system timing slot
Main features: high bandwidth backplane, high performance, modular design, strong scalability
2. Main specifications and characteristics
Slot configuration:
Hybrid slots: 8, supporting PXI and PXI Express hybrid modules.
PXI Express slots: eight, designed for high-speed data transmission and signal processing.
System timing slot: 1, used to improve clock accuracy and implement external clock and trigger routing.
Bandwidth and Performance:
Dedicated bandwidth of up to 1 GB/s per slot and system bandwidth of up to 4 GB/s are suitable for high-throughput data transfer applications.
Support for PXI and PXI Express modules for a wide range of test and measurement needs.
Power and heat dissipation:
Provides 791W of total power to ensure the stable operation of high power modules.
The operating temperature range can be extended to 55°C to meet the needs of various environmental conditions.
Sync and trigger:
All features of the latest PXI specification are integrated, including support for PXI and PXI Express modules.
A built-in 10 MHz reference clock and PXI trigger bus are provided for the PXI module, as well as a built-in 100 MHz reference clock, SYNC 100 and PXI star differential trigger for the PXI Express module, ensuring precise synchronization and trigger capabilities.
Compatibility and extensibility:
Compatible with PXI, PXI Express, CompactPCI, and CompactPCI Express modules, and supports plug and play of multiple modules.
It can be used as a solution for higher channel density systems to meet future expansion needs.
3. Application scenarios
The NI PXIe-1075 chassis is widely used in electronic testing, automated testing, scientific research, industrial control and other fields, and is suitable for applications requiring high-performance data acquisition, signal processing and analysis. Its modular design allows users to flexibly configure the system according to specific requirements to meet the needs of different test scenarios.
