Description

I. Product overview
Brand: GE (General Electric)
Model: DS200DSFBG2A
Type: Circuit board component
Application system: Designed for Mark V systems
Second, technical characteristics and functions
Parallel feedback function:
DS200DSFBG2A, as a driver parallel feedback card, is mainly responsible for collecting and processing feedback signals from the driver or other control components to ensure that the system can run accurately and stably.
High compatibility:
The product is highly compatible with Mark V systems and can be seamlessly integrated into GE’s industrial automation control systems.
Modular design:
Modular design for easy installation, maintenance and upgrade.
Built-in communication function:
Multiple communication protocols, such as SRTP and Modbus TCP/IP, are supported for easy data exchange with other control devices and systems.
Multiple fieldbus interfaces:
Provides a variety of fieldbus interfaces to support distributed control and/or I/O, and users can choose the appropriate interface module according to their needs.
Programming support:
It can be programmed through Proficy Logic Developer PLC Machine Edition and supports several programming languages such as Ladder Diagram (LDI), Instruction List (IL), Structure Text (ST) and C block.
3. Specification parameters
Analog output: 8
Accuracy varies with temperature: full scale 0.004% /°C
Loop voltage: 6… 30V DC
Fault type: Open 4… 20mA
Maximum voltage drop: < 30V 25mA
Bus current requirement: 550 MA
Analog output range: 0… 20mA 0… 20000 items
Maximum power consumption (W) : 5W
Operating temperature range: cooling water -40°C to +80°C
Maximum DC voltage: 500-900VDC
Dc voltage: 50-400VDC, 100-820VDC
Busbar capacitance: 880-600μ
4. Application field
DS200DSFBG2A is widely used in the field of industrial automation, especially in the control system that requires high precision, high stability and high reliability, such as power plants, petrochemical industry, metallurgical industry, paper industry, etc.
