Description

I. Product overview
Brand: General Electric
Model: DS200DDTBG2A
Type: Servo I/O terminal board
Main Uses: As a simplex servo I/O terminal board, used in Mark VI control system, processing and control of various industrial equipment data input and output.
Second, product characteristics
Isolated 12-bit analog output board:
The board provides high-precision analog output functions and supports 12-bit resolution, which is suitable for scenarios requiring high-precision analog signal processing.
Multifunctional I/O interface:
Features two servo outputs, I/O interfaces for six LVDT position sensors, and two active pulse rate inputs for flow monitoring. These interfaces can meet the control needs of a variety of industrial equipment.
High density terminal:
Use high-density Euro-Block terminals for easy connection and maintenance. In addition, multiple ground screws are provided to ensure the safety and reliability of the device.
Modular design:
Compact design for easy installation and stacking on DIN rails, saving cabinet space. At the same time, the modular design makes equipment maintenance and upgrading more convenient.
Intelligent control:
It supports a variety of control strategies, such as speed control and position control, to meet the control requirements in different industrial scenarios.
3. Technical specifications
Working voltage: 230V
Output frequency: 560kHz
Origin: USA
Product certification: Qualified
Series: 26506506
Bom number: DS200DDTBG2A
Mechanical life: ≥1 million times
Electrical life: ≥ 100,000 times
Protection characteristics: overcurrent protection is greater than 100% of the set current value, undercurrent protection is set in the range of 20%60%, and the protection time can be set in the range of 1s30s.
4. Application field
The GE DS200DDTBG2A is widely used in industrial automation, especially in control systems requiring high-precision analog outputs and multifunctional I/O interfaces. It can be used for data acquisition, processing and control of various industrial equipment, such as turbines, generators, compressors, etc.
