Description

The GE DS200DCFBG1BJB is a high-performance, highly reliable digital servo drive manufactured by General Electric (GE). The following is a detailed analysis of the product:

I. Product overview
The GE DS200DCFBG1BJB is primarily used in industrial automation and control systems, where it is able to connect thermocouple sensors, measure temperatures and transmit these temperature data to the control system. In addition, the module also has sensor status monitoring and diagnosis functions, provides control level power for drivers and cabinet fans, and is suitable for a variety of GE driver applications, such as DC2000, CB2000, FC2000, GF2000, ME2000 and AC2000.

Two, the main characteristics
High precision:
Temperature measurement based on thermocouple sensors to provide accurate temperature data.
Multi-function:
In addition to temperature measurement, it also has sensor condition monitoring and diagnostic functions.
Widely used:
Suitable for a wide range of GE drive applications, providing critical support for industrial automation and control systems.
Control level power supply:
Provides stable control level power supply for drivers and cabinet fans to ensure stable system operation.
Easy to configure:
The board features configurable jumpers and DIP switches for easy setup and adjustment as needed.
Indicator function:
Equipped with LED and neon indicators to indicate fuse status and power status.
Iii. Technical parameters (part)
Rated power: 200 W
Rated voltage: DC 24 V
Rated current: 8 A
Peak current: 16 A
Speed range: 0 to 3000 rpm
Torque range: 0 to 1.5 Nm
Accuracy: ± 0.01%
Operating temperature: -10 to 60 °C
Storage temperature: -40 to 85 °C
Size: 200 mm x 100 mm x 60 mm
Weight: 2 kg
4. Application field
The GE DS200DCFBG1BJB is used in a wide variety of industrial applications requiring accurate temperature measurement and control, including but not limited to:

Robot
Numerical control machine tool
Packaging machinery
Printing machinery
Textile machinery
Food processing machinery
Electronic manufacturing
V. Summary
The GE DS200DCFBG1BJB is a high-performance, highly reliable digital servo driver that provides critical temperature measurement and control functions for industrial automation and control systems.
