Description

I. Product overview
Model: DS200CTBDG1A
Brand: GE (General Electric)
Applications: Mainly used in the control systems of turbines, including steam and gas turbines, as a key component of the Mark V Speedtronic system.
Second, technical characteristics
Integrated features: The DS200CTBDG1A is an integrated protection, monitoring and control system designed for mechanical and generator applications of turbines.
Communication capability: The module communicates with other points and boards in the system via IONet (Ethernet) communication links, while supporting RS-232 9-pin d-shell wired connections.
Location and installation: Usually installed in the C core of the Mark V system, it is located in the universal data processor and is responsible for the transmission of Ma input and Ma output signals.
Electrostatic sensitivity: As an electrostatic sensitive component, you are advised to use an ESD wrist strap to prevent electrostatic accumulation from damaging the component or causing electric shocks.
3. Technical parameters
Input voltage: 24VDC
Output voltage: 5VDC
Operating temperature range: -40℃ to +85℃
Dimensions: 100mm × 50mm × 20mm
4. Application environment
The DS200CTBDG1A is designed to operate in harsh environments and is equipped with a rugged display panel to ensure long-term performance. It is mainly used in industrial control systems, especially control and monitoring systems related to gas turbines.
