Description

I. Product overview
The Bently 3500/40-01-00 Displacement monitoring module is a four-channel monitor capable of receiving input signals from Bently Nevada proximity sensors and processing these signals to generate a variety of vibration and displacement measurements. The module is not only limited to displacement monitoring, but also can be used to measure many parameters such as radial vibration, axial displacement, differential expansion and axial eccentricity.

2. Main functions and characteristics
Multi-channel monitoring: Four-channel simultaneous monitoring is supported, which improves the efficiency and accuracy of monitoring.
High-precision measurement: With high-precision measurement capabilities, can accurately reflect the vibration and displacement of mechanical equipment.
Programmable alarm: The user can set a programmable alarm threshold for the monitoring parameters according to the actual needs. When the monitoring value exceeds the threshold, the system will automatically send an alarm signal.
Easy configuration: With the 3500 framework configuration software, users can easily configure each channel, including sensitivity, alarm setting points, etc.
Widely used: suitable for all kinds of mechanical equipment in the manufacturing industry, such as steam turbines, compressors, generators, etc.

3. Technical parameters
Type: four-channel displacement monitor
Input: Receives input from the Bently Nevada proximity sensor
Measurement parameters: radial vibration, axial displacement, differential expansion, axis eccentricity, etc
Sensitivity:
Radial vibration: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
Axial displacement: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
Eccentricity: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)
Differential expansion: 0.394 mV/μm (10 mV/mil) or 0.787 mV/μm (20 mV/mil)
Accuracy: pass frequency and gap: ±0.33% of full scale, up to ±1%; 1X & 2X: ±0.33% of full scale, up to ±1%
Iv. Application scenarios
The Bently 3500/40-01-00 displacement monitoring module is widely used in applications requiring high-precision vibration and displacement monitoring, such as rotating machinery equipment in the electric power, petrochemical, metallurgical and other industries. By monitoring the vibration and displacement of mechanical equipment in real time, potential faults can be discovered and dealt with in time to ensure the safe and reliable operation of mechanical equipment.
