Description

The ABB PM862K01 3BSE076940R1 is an industrial automation controller unit manufactured by ABB with high performance and multiple functions for a wide range of industrial automation systems. The following is a detailed analysis of the product:

1. Basic information
Model: PM862K01 3BSE076940R1
Brand: ABB
Features: Standards-based hardware for optimal communication connectivity to support industrial automation control tasks
Second, technical characteristics
Hardware composition:
The CPU motherboard contains the microprocessor and RAM memory, real-time clock, LED indicator, INIT button, and CompactFlash interface.
The controller baseboard is equipped with two RJ45 Ethernet ports (CN1, CN2) and two RJ45 serial ports (COM3, COM4), where COM3 is the RS-232C port with the modem control signal, and COM4 is isolated for connecting configuration tools.
Redundancy and Reliability:
CPU redundancy is supported for high availability (including CPU, CEX bus, communication interface, and S800 I/O).
The controller is fully EMC certified to ensure stable operation in electromagnetic environments.
Communication capability:
Standards-based hardware to achieve the best communication connection, support Ethernet, PROFIBUS DP and other communication protocols.

Built-in redundant Ethernet communication port to improve communication reliability and stability.
Modularity and Extensibility:
The modular design allows for gradual expansion to meet different control needs.
It can be configured as 800xA control builder for easy system integration and management.
Other features:
The controller has IP20 class protection and can be used in general industrial environments without additional housing.
Equipped with real-time clock to ensure time synchronization and recording function.
LED indicators and INIT buttons provide intuitive status indication and ease of operation.
3. Performance parameters
Clock frequency: 67 Mhz
Performance: 1000 Boolean operation 0.18 ms
Memory: 32 MB RAM (for applications), 23.521 MB flash memory (for storage)
Power supply: 24 volts DC (19.2 volts -30 volts DC), maximum power consumption of 8.6 watts
Operating temperature: +5 to +55°C for operation, -40 to +70°C for storage
Dimensions: Width 119 mm, height 186 mm, depth 135 mm, weight 1200 g (including base)
4. Application field
ABB PM862K01 3BSE076940R1 is widely used in industrial automation fields, such as motor control, process control, production line automation, etc. Its high performance, reliability and flexibility make it the controller of choice for many industrial automation projects.
