ABB PM856K01 3BSE018104R1 Automatic control module

Description

The ABB PM856K01 3BSE018104R1 is an automation control module that belongs to ABB’s PM8 family. The following is a detailed analysis of the module:

1. Basic information
Model: PM856K01 3BSE018104R1
Brand: ABB
Series: PM8 series
Second, technical characteristics
Modular design:
The module has a modular design that allows for gradual expansion and easy configuration according to the needs of the control system.
The controller can be configured with 800xA control builder with full EMC certification.
Communication capability:
Supports a variety of communication protocols, such as Profibus DP, FF, Modbus, etc.
Built-in redundant Ethernet communication port provides powerful network communication capability.
The controller can connect up to 12 communication modules to meet complex communication needs.
Processor performance:
It is equipped with a RISC 32-bit real-time multi-tasking microprocessor with 16 MB RAM for error detection and correction.
Built-in temperature detection equipment ensures stable operation of the module in harsh environments.
Redundancy and Reliability:
The system supports redundancy Settings to ensure that when an important control unit fails, the relevant redundant units can be switched to the working unit without disturbance in real time, ensuring the safety and reliability of the system.
A backup battery for RAM is installed on the controller module to ensure data protection in case of system loss of power.
I/O scalability:
There is a port on the right side of the controller that can connect up to 12 S800 I/O modules and 192 S800 I/O points through the electrical ModuleBus.
The I/O modules can be expanded using the fiber-optic ModuleBus connector to connect up to seven S800 I/O clusters.
The system can also be extended to more I/O clusters via the Profibus DP bus, or even installed remotely.
3. Application and configuration
Application: The module is widely used in industrial automation control system, such as motor control, valve control, process control and so on.
Settings:
Convenient configuration: the type and quantity of modules can be determined according to the needs of the control system, and ordered to the market.
Easy installation: PLC hardware installation is simple, external wiring has a connector, simple wiring.
Easy programming: PLC internal logic device is rich, instruction system is perfect, can easily achieve a variety of control functions.
